Display

11.6” FHD (1920 x1080)

Optional 1000 nits DynaVue® sunlight readable display with capacitive multi-touch screen

Optional with digitizer

User selectable touch mode for Finger/Water, Glove, or Stylus programmable function

Operating System

Windows® 11 Pro 64-bit

Processors

Intel® Core™ i7-1250U (12th Gen) Processor with vPro™ (12MB Cache, up to 4.7 GHz, 2P+8E cores)

Intel® Core™ i5-1230U (12th Gen) Processor with vPro™ (12MB Cache, up to 4.4 GHz, 2P+8E cores)

Memory

Onboard 8GB up to 32GB (LPDDR4x)

Storage

256GB NVMe PCIe SSD

Optional 512GB/1TB/2TB PCIe SSD

Optional OPAL 2.0 SSD

Graphics

Intel® Iris® Xe Graphics

Camera

Integrated 2.0MP front-facing camera

Optional 11.0MP auto-focus rear camera with flash

Optional 5.0MP IR camera for Windows Hello

Audio

Integrated microphone

Intel® High Definition Audio Compliant

Integrated speaker x 2

I/O Ports

Thunderbolt 4 x 1

USB 3.2 Gen1 (type A) x 1

Audio in/out (combo jack) x 1

microSD card (microSDHC, microSDXC) x 1

10/100/1000 Ethernet (RJ45) x 1

Docking connector (20-pin Pogo) x 1

Nano SIM card x 1

DC-In jack x 1

Optional smart card reader x 1 or x 2

Optional USB 3.2 Gen2 (type C) x 1

Optional 2nd USB 3.2 Gen1 (type A) x 1

Optional USB 2.0 (type A) x 1

Optional serial port (RS232, 422 and 485 : D-sub, 9-pin) x 1

Optional 1D/2D barcode reader x 1

Optional RF antenna pass-through for GPS, WWAN, and WLAN

Expansion Slots

Optional ExpressCard 54 or LF/HF-RFID (NFC) or 2nd smart card reader

Keyboard & Input

5 buttons (2 user-definable keys)

Communications

Integrated 10/100/1000 Ethernet

Intel® Wi-Fi 6E AX211 (802.11ax)

Bluetooth® V5.3

Optional dedicated GPS module (UBLOX-NEO-M9N)

Optional 4G LTE multi-carrier mobile broadband

Optional 5G (project based)

Optional RF antenna pass-through for GPS, WWAN, and WLAN

Security

Intel® vPro™ Technology

Secured-core PC

TPM 2.0

NIST BIOS compliant

Easy removable SSD

Stealth mode

Kensington lock

Optional smart card reader x 1 or x 2

Optional Windows Hello

Optional night vision mode

Optional fingerprint scanner

Optional LF/HF-RFID (NFC) reader

Power

AC adapter: 100-240V, 50Hz-60Hz, 65W

Main battery: Li-Ion, 7.6V, 4800mAh, 10 hours

Optional hi-cap battery Li-Ion 7.6V, 9600mAh, 20 hours

Optional bridge battery: 5 minutes swap time

Dimension & Weight

317 mm (L) x 215 mm (W) x 23.8 mm (H)

1.39 kg

Warranty

3-year limited warranty standard
